09.070.0103: Stucco Assembly – Stucco Over CMU with Insulation

This detail shows a three coat Portland cement stucco assembly applied over self-furring lath with two layers of weather resistive barrier (WRB) behind the lath. The structural backup is concrete masonry, with rigid insulation between Z-channel furring. A 1/4″ scratch coat and 1/2″ brown coat make up the base coat, with a finish coat on […]

09.080.0101: Stucco Assembly – Sheathed Construction, Steel Framing

This detail shows a three coat Portland cement stucco assembly applied over self-furring lath to a backup of metal studs and sheathing. Two layers of weather resistive barrier (WRB) are used behind the lath. A 1/4″ scratch coat and 1/2″ brown coat make up the base coat, with a finish coat on the surface.

09.090.0101: Stucco Assembly – Sheathed Construction, Wood Framing

09.090.0101: Stucco Assembly - Sheathed Construction, Wood Framing This detail shows a three coat Portland cement stucco assembly applied over self-furring lath to a backup of wood studs and sheathing. Two layers of weather resistive barrier (WRB) are used behind the lath. A 1/4" scratch coat and 1/2" brown coat make up the base coat, [...]

09.070.0101: Stucco Assembly – Direct Applied, Concrete Masonry

09.070.0101: Stucco Assembly - Direct Applied, Concrete Masonry This detail shows a three coat Portland cement stucco assembly direct-applied to a backup of concrete masonry with flush joints. A 1/4" scratch coat and 1/2" brown coat make up the base coat, with a finish coat on the surface. DOWNLOAD DETAILDynamic 3D Detail Explore this detail [...]
